Outdoor GYTS+2*4mm² Optical Cable Steel wire 12F
製品概要
GYTS+2*4mm² 屋外用光ケーブルは、12 本のファイバーと 2 本の電源線を統合しています。防水設計、機械的耐久性、データと電力の同時伝送が特徴です。通信ネットワーク、FTTH、カスタム長を利用できる監視プロジェクトに最適です。
製品カスタム属性
製品名:
屋外 GYTS+2*4mm² 光ケーブル 鋼線 12F
繊維数:
12
コーティング:
125μm
コーティング(±5μm):
250μm
ルーズチューブ径(mm):
2 mm
ゆるいチューブ材料:
PBT/PP
強度メンバー中央補強:
鋼鉄線/PE蓋付き鋼鉄線
シース シース材質:
MDPE/HDPE
色:
黒
ケーブルの重量（kg/km）:
360
動作温度:
-20℃～70℃
繊維ブランド:
コーニング,YOFC,OFS,ドラカ
ハイライト:
Outdoor GYTS fiber optic cable
,12F steel wire optical cable
,4mm² armored fiber cable
基本プロパティ
起源の場所:
中国、深Shenzhen
ブランド名:
DF/OEM/Nuetral
証明:
CE/ROHS/REACH/ISO9001/ISO14001
モデル番号:
屋外 GYTS+2*4mm² 光ケーブル 鋼線 12F
取引物件
最小注文数量:
交渉可能
価格:
negotiable denpend on QTY
パッケージの詳細:
ブリスターボックス+カートン
受渡し時間:
5~9 営業日 QTY に依存する
支払条件:
ウェスタンユニオン,T/T,MoneyGram/Paypal
供給の能力:
1000個/日
製品説明
Outdoor GYTS+2*4mm² Optical Cable Steel wire 12F
The fibers,250μm,are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound.
The cable core is FRP or metallic strength member( some structures need add PE as bedding layer in the strength member). Electric wires and tubes (and fillers) are stranded around the strength member into a compact and circular cable core. The cable core is filled with the filling compound to protect it from water ingress. After two sides PSP are longitudinally applied over the inner sheath ,the cable is completed with PE or LSZH outer sheath.
Outdoor GYTS+2*4mm² Optical Cable Applications
-
Telecommunications network;
-
Construction of communication base stations in villages, remote areas in cities and towns ;
-
Residential areas and buildings FTTH;
-
Security monitoring project;
-
Others occasion which information together with electric power at the same time.
Outdoor GYTS+2*4mm² Optical Cable Features
-
Good mechanical and temperature performance;
-
Opto and electricity integrated, fully save pipeline resources;
-
Electric and optical cable maintain relatively independent structure, easy to import; export and link when installation;
-
Electricity lines, telephone lines, television lines, network lines, monitor lines and data lines are multi-one network, saves costs;
-
Larger operating temperature range;
-
Larger construction temperature range;
-
Cable diameter and bending radius are small, freely install in small space and compatible with optical signal and electric energy transmission.
Outdoor GYTS+2*4mm² Optical Cable Parameter and Properties
| Optical fiber type | G.652D | G.655 | 50/125um | 62.5/125um | |
|
Attenuation |
@850nm |
... |
... |
≤3.5 dB/km |
≤3.5 dB/km |
|
@1300nm |
... |
... |
≤1.5 dB/km |
≤1.5 dB/km |
|
|
@1310nm |
≤0.36 dB/km | ≤0.40 dB/km |
... |
... |
|
|
@1550nm |
≤0.22 dB/km |
≤0.23dB/km |
... |
... |
|
|
Bandwidth |
@850nm |
... |
... |
≥500 MHz·km |
≥200 MHz·km |
|
@1300nm |
... |
... |
≥1000 MHz·km |
≥600 MHz·km |
|
|
Numerical Aperture |
... |
... |
0.200±0.015NA |
0.275±0.015NA |
|
|
Cable Cut-off Wavelengthλcc |
≤1260nm |
≤1480nm |
... |
... |
|
Outdoor GYTS+2*4mm² Optical Cable Structure
Other Requirements
Length of production optical cable:2000M
Optical cable outer sheath printing specifications, such as:
OPTICAL FIBER CABLE GYTS-12B1.3+2*4MM 12.5 MM/YY 00000M
Why choose TAKFLY?
Professional manufacturer:
- With more than 25 years manufacturing experience in Fiber optic products
- More than 450 assembly workers with 3 years experienced
- More than 10 R&D Engineers
- 16 Sets Germany imported Injection Machine and 16 Production Lines
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, etc.
- OEM Brand is acceptable
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Soure Electronic Exhibition, etc.
Quality Control
- Spot check the raw material incoming inspection before production
- Fully check after every individual process finished
- Fully check production half done
- Fully check the finished products before packing
- Spot check before shipping
Delivery
- Samples: 1-3 working days
- Mass Production Order: 3-7 working days
- Packaging: Plastic Bag, Carton and Pallet are available according to your request
If you're interested in our products or have any doubt, feel free to contact me at any time!
